HDPE smooth geomembrane

Product introduction：Ordinary high-density polyethylene geomembrane is using HDPE as raw materials and produced by

blow molding process.

Product specifcation：thickness 0.1-3.0mm, width 1-12m, length according to engineering design and customer requirements.

Product features：Excellent resistance to environmental stress cracking, excellent resistance to low temperature, aging and corrosion,

wide temperature range (-60 / + 60 ° C), long service life.

Scope of application：municipal environmental protection, anti-seepage project of water conservancy, anti-seepage project of

landscaping and waterscape, anti-seepage project of transportation infrastructure, anti-seepage project of

agricultural water conservancy, aquaculture industry and other prefabrication of temporary container structure

special components such as anti-seepage, anti-corrosion, leakage prevention, reinforcement, collection of

leachate, etc.

Product implementation standard：JT/T518-2004 Geosynthetics in Highway Engineerings-Geomembrane

GB / T17643-2011 Geosynthetics-polyethylene Geomembrane

0.2 - 3mm HDPE Geomembrane Damliner Smooth /Rough/Composite Geomembrane Pond Liner for Sale

Thickness	Smooth surface 0.2mm-3.0mm, textured surface 1.0mm-2.0mm
Width	Smooth surface 1m-8m, textured surface 4m-8m
Length	30m-200m/roll or as requested
Material	HDPE, LDPE, LLDPE
Classification	Smooth / Rough / Composite Geomembrane
Surface	Smooth surface, single surface textured,dual surfaces textured

Item	Geomembrane Customizable parameters
Thickness (mm)	0.30	0.50	0.75	1.00	1.25	1.50	2.00	2.50	3.00
Density ( g/cm3)	≧0.940
Tensile yield strength (N/mm)	≧4	≧7	≧10	≧13	≧16	≧20	≧26	≧33	≧40
Tensile fracture strength (N/mm)	≧6	≧10	≧15	≧20	≧25	≧30	≧40	≧50	≧60
Elongation at yield (%)	_	_	_	≧11
Elongation at break (%)	≧600
Right-angle tear load (N)	≧34	≧56	≧84	≧115	≧140	≧170	≧225	≧280	≧340
Puncture strength (N)	≧72	≧120	≧180	≧240	≧300	≧360	≧480	≧600	≧720
Carbon black content (%)	2.0~3.0

We provide smooth surface geomembrane, rough surface geomembrane, column point geomembrane manufacturing and custom services, please contact us to visit our samples and companies online

Longer service life,more than 4 years.

Geomembrane use 100% virgin raw material,adding carbon black, antioxidant,anti-aging and UV resistance component.It has higher tensile and puncture resistance and longer service life.

Strong technical force

Our company specializes in the production of geomembrane, there are professional product testing equipment and inspectors! Ensure the quality of each batch of geomembrane products.

HDPE Geomembrane liner are made from polyethylene polymer materials that blow molding,its main function is to prevent the liquid leakage and gas volatile. According to the production of raw materials can divide into HDPE geomembrane liner and EVA geomembrane liner,etc.

Our services:

Online technical support, Onsite Installation, Onsite Training, Onsite Inspection, Free spare parts, Return and Replacement

CHOOOSE YOUR FREE GIFT!

A. For orders over 1x20ft, we will give you a free welding machine worth $580.

B. For orders over 1x40FT, we will give you a free welding machine valued at $1450.

C. We will give away welders worth $580 and extruders worth $1,100 for cumulative orders over $150,000.

The products are used in agricultural fish pond fish and shrimp farming, engineering waterproof and landfill seepage prevention applications, with excellent physical characteristics by customers. Please contact us and together we can provide sustainable solutions.
